Features:
- User-friendly configuration via GATE Control Station app
- Makes firmware updates via internet
- Proximity trigger sensor offering 250 possible sensitivity settings
- Innovative optical sensors instead of mechanical switches
- Access to Statistics and Rankings
- Replicates trigger response
- Compatible with V2 gearboxes (including CNC) without any modifications needed
- Compatible with most powerful AEG replicas
SENSORS
Choose one of the two trigger modes and then calibrate even finer with 250 possible sensitivity settings!
- 1-stage: Standard
- 2-stage: First stage (SEMI/BURST), second stage (BURST/AUTO)
CONFIGURABLE FIRE SELECTOR
Two selector sensors allow you to use six fire selector modes, including innovative SEMI-BURST-AUTO mode.
- SAFE/ SEMI/ AUTO
- SAFE/ SEMI/ SEMI
- SAFE/ SEMI/ BURST
- SAFE/ BURST/ AUTO
- SAFE/ SEMI/ BURST-AUTO
- (short press-Burst, long press- Auto)
- SEMI/ BURST/ AUTO
- (Safe mode via fast switch Safe-Semi-Safe)
SNIPER DELAY
Lets you set delay between each SEMI shots to simulate the delay from reload or recoil.
Set options: 0.5s, 1s, 2s, 3s delay
MORE
Built in self-test allows you to quickly check that the module is working and locates problems if/when anything goes wrong.
Military Spec coating makes module resistant to atmospheric conditions.
Comes factory-fitted for low-resistance deans connectors. Includes a mini-tamiya adapter kit.
Drop-in module can be used with batteries up to and including 14.8v LiPo. Minimum operative voltage 3V, maximum 17V.
Adaptive active brake system automatically adjusts the motor's braking power according to your needs, prolonging the lifespan of your motor.
When the battery voltage drops to a predefined level, the motor will vibrate at regular intervals. When the voltage drops to critical level, it will cease firing.
FIRMWARE EDITIONS
Available in 3 firmware editions: BASIC, ADVANCED, EXPERT.
BASIC: Best for those who prefer simplicity but require quality. Economic version with limited functions.
ADVANCED: Best for those who like complex solutions. Advanced version with wide variety of functions. Enables access to Statistics and ASTER World Rankings
EXPERT: Best for experienced airsofterw. Vast diversity of settings and options combined with maximum configuration capabilities.
DIFFERENCES
| |
BASIC |
ADVANCED |
| Box Version |
Basic Module |
Complete Set Drop-in |
| Fire Selector Mode |
3 modes |
6 modes |
| Trigger Sensitivity Adjustment |
YES |
YES |
| Cycle Detection |
YES |
YES |
| Burst |
3rd |
2/3/4/5/8/10rd |
| Burst Mode |
FULL |
FULL/Trigger |
| Pre-cocking |
NO |
YES |
| ROF Control |
NO |
YES |
| Sniper Delay |
NO |
YES |
| Battery Protection |
YES |
YES |
| Low Battery Warning |
YES |
YES |
| Equalizer |
NO |
YES |
| AUG Mode |
YES |
YES |
| Manual Active Brake System |
YES |
YES |
| Statistics & Rankings |
NO |
YES |
| Diagnostic |
YES |
YES |
| Firmware Update |
YES |
YES |
